Chapter 4
Appendix
62
IA Net
XSEL-R/S
Listed below are the parameters related to IA Net. Refer to XSEL-R/S Instruction Manual for the
parameters of the XSEL controller main unit.
x I/O parameters
No. Parameter Name
Initial Value
(Reference) Input Range
Remarks
1 I/O Port Allocation Type 1 0 to 1
0 : Fixed Allocation (Recommended when IA Net
is used)
1 : Automatic Allocation
(Note) Priority of I/O Port Assignment when
automatically assigned
Input Port No.0 to 299
Output Port No.300 to 599
1) Network I/F Module 1
2) I/O Slots 1 (I/O 1) Mounting Board
(Note) I/O Slots 1 (I/O 1) Assigned for the
continuously mounted range from
mounting board = for safety
(Note) Priority of extension I/O ports at automatic
assignment
Input Port No.1000 to 3999
Output Port No.4000 to 6999
1) Network I/F Module 2
2) Extension I/O Unit
3) IA Net
20 Input Filtering Cycle 2 1 to 9
Input signal is identified after the condition is
retained for a period with two times or more of the
value set in this parameter.
602 IA Net Top Occupied Station
No.
0 0 to 63
Set the smallest number in the station numbers
(settable range from 0 to 63) that the controller
occupies.
603 IA Net Resizing Station No. 0 0 to 63
Station number to optimize the communication
cycle time at the IA Net startup
(Note) Have the same value set in common for all
the controllers in the same network.
(Recommendation: Set the smallest value
available to assign in all the station
numbers available for assignment in the
shared memory.)
604 IA Net Final Station No. 63 1 to 63
Final station number in the same network
(Note) Have the same value set in common for all
the controllers in the same network.
(Recommendation: Set the biggest value
available to assign in all the station
numbers available for assignment in the
shared memory.)
605 IA Net All Connected Station
Patterns (31-00)
0
H
0 to
FFFFFFFF
H
With 0: Disconnected and 1: Connected, make the
connection conditions of Stations No.31 to No.0 in
bit patterns and convert them into the hexadecimal
numbers to input.
606 IA Net All Connected Station
Patterns (63-32)
0
H
0 to
FFFFFFFF
H
With 0: Disconnected and 1: Connected, make the
connection conditions of Stations No.63 to No.32
in bit patterns and convert them into the
hexadecimal numbers to input.
607 IA Net Error Monitor 1 0 to 5
0 : No Monitoring
1 : Monitoring
2 : Monitoring (Monitoring only on the errors
related to link error)
(Note 1) There are some exceptions
(Note 2) IA Net Link Error occurs when the
duration of the condition being in the
network link error exceeds the value set
in IA Net Network Link Error
Confirmation Timer. (Refer to I/O
parameter No.608)
