Chapter 3 Operation (Construction for Network)
60
IA Net
XSEL-R/S
x Example for I/O Parameter Settings
Example for
Setting
No. Parameter Name
XSEL1 XSEL2
Input Range Remarks
1 I/O Port Allocation Type 0 0 0 to 1
0 : Fixed Allocation
1 : Automatic Allocation
602 IA Net Occupied Station Top
No.
0 2 0 to 63
603 IA Net Resizing Executed
Station No.
0 0 0 to 63
Station number to optimize the
communication cycle time at the IA Net
startup
604 IA Net Final Station No. 63 63 1 to 63
Final station number in the same network
Note Have the same value set in common
for all the controllers in the same
network.
605 IA Net All Connected Station
Patterns (31-00)
5
H
5
H
0 to
FFFFFFFF
H
With 0: Disconnected and 1: Connected,
make the connection conditions of Stations
No.31 to No.0 in bit patterns and convert
them into the hexadecimal numbers to
input.
606 IA Net All Connected Station
Patterns (63-32)
0
H
0
H
0 to
FFFFFFFF
H
With 0: Disconnected and 1: Connected,
make the connection conditions of Stations
No.63 to No.32 in bit patterns and convert
them into the hexadecimal numbers to
input.
691
Extension Input Port Start
Number at IA Net Fixed
Assignment
1000 1000 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
692
Extension Output Port Start
Number at IA Net Fixed
Assignment
4000 4000 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
693
IA Net Common Input
Acquisition Shared Word
Patterns (31-00)
F00
H
F
H
0 to
FFFFFFFF
H
0
b
: Not to Acquire
1
b
: To Acquire
Note 16 points can be acquired from one
word
694
IA Net Common Input
Acquisition Shared Word
Patterns (63-32)
0
H
0
H
0 to
FFFFFFFF
H
695
IA Net Common Input
Acquisition Shared Word
Patterns (95-64)
0
H
0
H
0 to
FFFFFFFF
H
696
IA Net Common Input
Acquisition Shared Word
Patterns (127-96)
0
H
0
H
0 to
FFFFFFFF
H
697
IA Net Common Input
Acquisition Shared Word
Patterns (159-128)
0
H
0
H
0 to
FFFFFFFF
H
698
IA Net Common Input
Acquisition Shared Word
Patterns (191-160)
0
H
0
H
0 to
FFFFFFFF
H
699
IA Net Common Input
Acquisition Shared Word
Patterns (223-192)
0
H
0
H
0 to
FFFFFFFF
H
700
IA Net Common Input
Acquisition Shared Word
Patterns (255-224)
0
H
0
H
0 to
FFFFFFFF
H
701 IA Net Shared Number of
Outputs Use
64 64 0 to 256
Multiples of 16
Note One station is occupied for every 64
points.
