Chapter 3 Operation (Construction for Network)
41
IA Net
XSEL-R/S
Station Numbers and Shared Word Numbers on Extension I/O Unit
Rotary Switch
(unit number
setting)
Station No.
Shared Word
No.
0 0 to 3 0 to 15
1 4 to 7 16 to 31
2 8 to 11 32 to 47
3 12 to 15 48 to 63
4 16 to 19 64 to 79
5 20 to 23 80 to 95
6 24 to 27 96 to 111
7 28 to 31 112 to 127
8 32 to 35 128 to 143
9 36 to 39 144 to 159
A 40 to 43 160 to 175
B 44 to 47 176 to 191
C 48 to 51 192 to 207
D 52 to 55 208 to 223
E 56 to 59 224 to 239
F 60 to 63 240 to 255
XSEL1 XSEL2 XSEL3 Slot
No. Input Output Input Output Input Output
1
ż
(32 points)
㩷 㩷 㩷 㩷 㩷
2
㩷 㩷 㩷
ż
(16 points) 㩷 㩷
3
㩷 㩷 㩷 㩷
ż
(16 points)
ż
(32 points)
4
㩷 㩷 㩷 㩷
ż
(48 points) 㩷
Parameters
No.705
2 10 2300
XSEL First Units
IA Net Related Parameters Set Value
1 I/O Port Allocation Type 0
602 Top Occupied Station Number 0
603 Resizing executed station number 0
604 Final station number 15
605 All Connected Station Patterns (31-00) F1FF
606 All Connected Station Patterns (63-32) 0
691 Input Port Start No. in Network I/F 1000
692 Output Port Start No. in Network I/F 4000
693 Shared memory reference word pattern (31-00) (Note 1) 01070000
694 Shared memory reference word pattern (63-32) (Note 1) 1000000
695
to
700 Shared memory reference word pattern
(255-64) (Note 1) 0
701 Output Ports (Note 2) 208
705 Extension I/O Unit Use Select 2
706 Unit Number of Extension I/O Unit 3
707 Start number of extension input ports at
fixed assignment for Slot 1 1080
708 Start number of extension output ports at
fixed assignment for Slot 1 -1
709 Start number of extension input ports at
fixed assignment for Slot 2 -1
710 Start number of extension output ports at
fixed assignment for Slot 2 -1
711 Start number of extension input ports at
fixed assignment for Slot 3 -1
712 Start number of extension output ports at
fixed assignment for Slot 3 -1
713 Start number of extension input ports at
fixed assignment for Slot 4 -1
714 Start number of extension output ports at
fixed assignment for Slot 4 -1
XSEL Secound Units
IA Net Related Parameters Set Value
1 I/O Port Allocation Type 0
602 Top Occupied Station Number 4
603 Resizing executed station number 0
604 Final station number 15
605 All Connected Station Patterns (31-00) F1FF
606 All Connected Station Patterns (63-32) 0
691 Input Port Start No. in Network I/F 1000
692 Output Port Start No. in Network I/F 4000
693 Shared memory reference word pattern (31-00) (Note 1) 100001FF
694 Shared memory reference word pattern (63-32) (Note 1) 10003
695
to
700 Shared memory reference word pattern
(255-64) (Note 1) 0
701 Output Ports (Note 2) 80
705 Extension I/O Unit Use Select 10
706 Unit Number of Extension I/O Unit 3
707 Start number of extension input ports at
fixed assignment for Slot 1 -1
708 Start number of extension output ports at
fixed assignment for Slot 1 -1
709 Start number of extension input ports at
fixed assignment for Slot 2 -1
710 Start number of extension output ports at
fixed assignment for Slot 2 4080
711 Start number of extension input ports at
fixed assignment for Slot 3 -1
712 Start number of extension output ports at
fixed assignment for Slot 3 -1
713 Start number of extension input ports at
fixed assignment for Slot 4 -1
714 Start number of extension output ports at
fixed assignment for Slot 4 -1
XSEL Third Units
IA Net Related Parameters Set Value
1 I/O Port Allocation Type 0
602 Top Occupied Station Number 7
603 Resizing executed station number 0
604 Final station number 15
605 All Connected Station Patterns (31-00) F1FF
606 All Connected Station Patterns (63-32) 0
691 Input Port Start No. in Network I/F 1000
692 Output Port Start No. in Network I/F 4000
693 Shared memory reference word pattern (31-00) (Note 1) 00191E03
694 Shared memory reference word pattern (63-32) (Note 1) 30000
695
to
700 Shared memory reference word pattern
(255-64) (Note 1) 0
701 Output Ports (Note 2) 32
705 Extension I/O Unit Use Select 2300
706 Unit Number of Extension I/O Unit 3
707 Start number of extension input ports at
fixed assignment for Slot 1 -1
708 Start number of extension output ports at
fixed assignment for Slot 1 -1
709 Start number of extension input ports at
fixed assignment for Slot 2 -1
710 Start number of extension output ports at
fixed assignment for Slot 2 -1
711 Start number of extension input ports at
fixed assignment for Slot 3 1176
712 Start number of extension output ports at
fixed assignment for Slot 3 4032
713 Start number of extension input ports at
fixed assignment for Slot 4 1192
714 Start number of extension output ports at
fixed assignment for Slot 4 -1
Extension I/O unit 䎃 input ports connected directly excluded
Extension I/O unit 䎃 input ports connected directly excluded
Expansion I/O units Rotary Switch (unit number setting) 3
Number of I/O points for Slot 1 I/O=32/16
Number of I/O points for Slot 2 I/O=32/16
Number of I/O points for Slot 3 I/O=16/32
Number of I/O points for Slot 4 I/O=48/48
Note 1 Establish the settings with a care not to include the input ports
of an extension I/O unit that XSEL controller directly controls
(which is set in Parameter No. 705) in the word pattern.
Note 2 Establish the settings with a care not to include the output ports
of an extension I/O unit that XSEL controller directly controls
(which is set in Parameter No. 705) in the number of used
output ports.
