Chapter 3 Operation (Construction for Network)
58
IA Net
XSEL-R/S
No. Parameter Name
Example
for Setting Input Range
Remarks
707
Extension Input Port Start Number at
Extension I/O Unit Slot 1 Fixed
Assignment
1000 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
708
Extension Output Port Start Number
at Extension I/O Unit Slot 1 Fixed
Assignment
4000 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
709
Extension Input Port Start Number at
Extension I/O Unit Slot 2 Fixed
Assignment
1032 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
710
Extension Output Port Start Number
at Extension I/O Unit Slot 2 Fixed
Assignment
4016 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
711
Extension Input Port Start Number at
Extension I/O Unit Slot 3 Fixed
Assignment
-1 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
712
Extension Output Port Start Number
at Extension I/O Unit Slot 3 Fixed
Assignment
-1 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
713
Extension Input Port Start Number at
Extension I/O Unit Slot 4 Fixed
Assignment
-1 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
714
Extension Output Port Start Number
at Extension I/O Unit Slot 4 Fixed
Assignment
-1 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
715 Extension I/O Unit Error Monitoring 0 1 Set this to 1
