Chapter 4
Appendix
64
IA Net
XSEL-R/S
No. Parameter Name
Initial Value
(Reference) Input Range
Remarks
701 IA Net Shared Number of
Outputs Use
0 0 to 256 Multiples of 16
702 (For extension)
703 (For extension)
704 (For extension)
705 Extension I/O Unit Use Select 0
H
0 to
FFFFFFFF
H
Bits 0 to 3 : Slot 1 Use Select
Bits 4 to 7 : Slot 2 Use Select
Bits 8 to 11 : Slot 3 Use Select
Bits 12 to 15 : Slot 4 Use Select
(0:Unused
1:Only output to be used
2:Only input to be used
3:Both output and input to be used)
706 Extension I/O Unit No. 0
H
0 to F
H
Set the unit number of the used extension I/O unit.
(Note) Extension I/O unit is that;
x Top station number = unit number × 4
x Number of occupied stations = 4
in IA Net network.
707
Extension Input Port Start
Number at Extension I/O Unit
Slot 1 Fixed Assignment
-1 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
708
Extension Output Port Start
Number at Extension I/O Unit
Slot 1 Fixed Assignment
-1 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
709
Extension Input Port Start
Number at Extension I/O Unit
Slot 2 Fixed Assignment
-1 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
710
Extension Output Port Start
Number at Extension I/O Unit
Slot 2 Fixed Assignment
-1 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
711
Extension Input Port Start
Number at Extension I/O Unit
Slot 3 Fixed Assignment
-1 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
712
Extension Output Port Start
Number at Extension I/O Unit
Slot 3 Fixed Assignment
-1 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
713
Extension Input Port Start
Number at Extension I/O Unit
Slot 4 Fixed Assignment
-1 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
714
Extension Output Port Start
Number at Extension I/O Unit
Slot 4 Fixed Assignment
-1 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
715 Extension I/O Unit Error
Monitor
0 0 to 5
0 : No Monitoring
1 : Monitoring
2 : Monitoring
(Not to monitor 24V I/O power related error)
3 : Monitoring
(To monitor only 24V I/O power related error)
4 : Monitoring (makes 24V I/O Power Supply
Related Error message level)
(Note) There are some exceptions
(Note) When it is set to 0 (= Not monitored) or 2
(=24V I/O Power Supply Related Error not
monitored), a system error would not be
generated even in an error related to 24V
I/O power supply, but the actual output
would not be executed for the protection
of the extension I/O unit.
