Chapter 4
Appendix
65
IA Net
XSEL-R/S
No. Parameter Name
Initial Value
(Reference) Input Range
Remarks
716
Extension I/O Unit
Multi-Channel DIO External
Terminal Block Overcurrent /
Power Supply Failure
Detection Input Indication
0
H
0 to
FFFFFFFF
H
Bits 0 to 3 : Extension I/O unit slot 1 input
indication
Bits 4 to 7 : Extension I/O unit slot 2 input
indication
Bits 8 to 11 : Extension I/O unit slot 3 input
indication
Bits 12 to 15 : Extension I/O unit slot 4 input
indication
(0: Error detection not to be input
1: Error detection input = use IN023 in card
2: Error detection input = use IN047 in card
3: Error detection input = use IN023/47 in card)
(Note) See the specification of the connected
terminal unit for the multi-channel DIO for
setting.
(Note) The input port used as the error detection
input cannot be used as a
general-purposed input port.
