Chapter 4
Appendix
63
IA Net
XSEL-R/S
No. Parameter Name
Initial Value
(Reference) Input Range
Remarks
608 IA Net Attribute 1 F000000
H
0 to
FFFFFFFF
H
Bits 0 to 7 : Network Link Error Confirmation
Timer Value (in 10ms unit)
(Note) Valid when I/O Parameter No.607 = 1 or 2
Bits 8 to 19 : System Reservation
Bits 20 to 23 : Select the IA Net link error level
(0 : Cold-start level alarms
1 : Message Level)
Bits 24 to 31 : Timeout duration (sec) for link waiting
at IA Net initializing
609 IA Net Attribute 2 F05
H
0 to
FFFFFFFF
H
Bits 0 to 7 : IAI Protocol B / SIO, IAI Protocol B /
TCP non-communication confirmation
timer value (sec)
(Time to become receivable condition
via IAI Protocol B / IA Net and other
controllers)
Bits 8 to 15 : IAI Protocol B / IA Net
non-communication confirmation
timer value (sec)
(Time to become receivable condition
for command via other controllers
after command received via IAI
Protocol B / IA Net and other
controllers)
Bits 16 to 23 : Value (sec) with “PC/TP Reconnection
Delay Time at Software Reset” added
when IA Net is used
610 IA Net Attribute 3 0
H
0 to
FFFFFFFF
H
611 (For extension) 0
0 to
FFFFFFFF
H
612 (For extension) 0
0 to
FFFFFFFF
H
613 to
678 System Reservation
… … …
679 to
690 (For extension)
0
0 to
FFFFFFFF
H
691
Extension Input Port Start
Number at IA Net Fixed
Assignment
-1 -1 to 3999 1000+(Multiples of 16)
(Setting is invalid if set to -1)
692
Extension Output Port Start
Number at IA Net Fixed
Assignment
-1 -1 to 6999 4000+(Multiples of 16)
(Setting is invalid if set to -1)
693
IA Net Common Input
Acquisition Shared Word
Patterns (31-00)
0
0 to
FFFFFFFF
H
694
IA Net Common Input
Acquisition Shared Word
Patterns (63-32)
0
0 to
FFFFFFFF
H
695
IA Net Common Input
Acquisition Shared Word
Patterns (95-64)
0
0 to
FFFFFFFF
H
696
IA Net Common Input
Acquisition Shared Word
Patterns (127-96)
0
0 to
FFFFFFFF
H
697
IA Net Common Input
Acquisition Shared Word
Patterns (159-128)
0
0 to
FFFFFFFF
H
698
IA Net Common Input
Acquisition Shared Word
Patterns (191-160)
0
0 to
FFFFFFFF
H
699
IA Net Common Input
Acquisition Shared Word
Patterns (223-192)
0
0 to
FFFFFFFF
H
700
IA Net Common Input
Acquisition Shared Word
Patterns (255-224)
0
0 to
FFFFFFFF
H
0
b
: Condition of this shared word area not to be
acquired
1
b
: Make condition of this shared word area able to
be acquired
Note 1 If this parameter is set to 1, the condition of
16-bit in the indicated area can be acquired.
Note 2 In this parameter, selection of to acquire /
not to acquire the condition of each bit can
be made with binary numbers, and is
converted into the hexadecimal system for
setting.
