Chapter 1 Specifications Check
17
IA Net
XSEL-R/S
Chapter 1 Specifications Check
1.1 Product Check
1.1.1 Parts
To use this function, it is necessary to prepare the following parts. Use the following list to
determine if all of the necessary components are available, and if there is anything missing,
contact your local IAI distributor.
No. Part Name Model Quantity Remarks
1
XSEL Controller
(XSEL-R/S related)
Refer to “How to read the
model plate”, “How to read
the model No.”
(Extension network board
should be inserted)
For number
of
constructing
units
For the accessories enclosed
to each controller, refer to the
instruction manuals of
XSEL-R/S related controllers
2
IA Net Dedicated
cable
CB-RS-IAN * * *
(Necessary to purchase
additions)
Number of
necessary IA
Net
* * * : Cable Length
Standard : 2m
Max : 10m (1m Unit)
3
Terminal Resistance
Unit
(Necessary to purchase
additions)
2 units / set 100: 1/2W
4 First Step Guide 1 part / set
5
Instruction Manual
(DVD)
1 piece / set
6 Safety Guide 1 part / set
1.1.2 Teaching Tool
A teaching tool such as PC software is necessary to perform commissioning of this product.
Any of the following teaching tools may be used.
No. Part Name Model
1
PC software
(with RS232C Cable + Emergency Stop Box)
IA-101-X-MW
2
PC software
(with USB conversion adaptor + USB Cable + Emergency Stop Box)
IA-101-X-USBMW
3
PC software
(with Safety Category 4 Compliance Type + Emergency Stop Box)
IA-101-XA-MW
4 Teaching pendant SEL-T
5 Teaching pendant (with deadman switch) SEL-TD
6
Teaching pendant
(with deadman switch + TP adapter (RCB-LB-TG))
SEL-TG
