Chapter 3 Operation (Construction for Network)
52
IA Net
XSEL-R/S
The bit data of the values set in No.693 to 700 are converted into the hexadecimal numbers for
settings.
Shown below is an example for No.693.
The value to set in No.693 is 8CEF0321
H
.
Reference Matching Table for Bit Data (Binary Numbers)
and Hexadecimal Numbers
Bit Data
(Binary Numbers)
Hexadecimal
Numbers
0000 0
0001 1
0010 2
0011 3
0100 4
0101 5
0110 6
0111 7
1000 8
1001 9
1010 A
1011 B
1100 C
1101 D
1110 E
1111 F
[Setting 2 : Output Port Settings]
1) Number of Used Ports Setting
No.
Parameter Name
(I/O parameters)
Initial Value
(Reference)
Input Range Remarks
701 IA Net Shared Number of
Output Use
0 0 to 256
Multiples of 16
* One station is occupied for every 64
points.
Set the number of the ports used for the output in IA Net in I/O Parameter No.701.
Note 1 The number of occupied stations is determined by the number of used output
ports.
Number of
Points used for
Output
Number of Occupied
Stations
0 0
16 to 64㩷 1㩷
80 to 128㩷 2㩷
144 to 192㩷 3㩷
208 to 256㩷 4㩷
Settings in No.693 1 0 0 0 1 1 0 0 1 1 1 0 1 1 1 1 0 0 0 0 0 0 1 1 0 0 1 0 0 0 0 1
Ļ Ļ Ļ Ļ Ļ Ļ Ļ Ļ Ļ
(Covert into
hexadecimal
numbers)
8 C E F 0 3 2 1
