14
IA Net
XSEL-R/S
7) Panel Unit Connector
This is a connector to plug in the optional panel unit.
8) to 11) Expanded I/O board (slot 1 to 4)
One I/O board can be inserted to each slot.
No. of Input points No. of Output points
Type
Model
NPN IA-103-X-32
32
16
PNP IA-103-X-32-P
NPN IA-103-X-16
16
32
PNP IA-103-X-16-P
NPN IA-10-3204-NP
48
48
PNP IA-10-3204-PN
There is a status LED above each slot, and it is used to monitor the condition of each I/O
board.
{
: Illuminating, × : OFF
Name
Lamp condition
Color
Description
{
Green
In the normal operation
I/O * RDY
(Note 1)
×
-
x
I/O Not to use
x
Error
x
I/O board not Equipped
Note 1 : Slot number comes to *
