15
IA Net
XSEL-R/S
Starting Procedures
When using this product for the first time, make sure to avoid omission and incorrect wiring by
referring to the procedure below. “PC” stated in this section means “PC software”.
No.ψ
ω Yes
ω
ω Yes
ω Yes
Check of Packed Items
Have all the items been delivered?
[Refer to this manual and an instruction manual
of each controller.] Please contact the distributor.
Installation and Wiring [Refer to Chapter 2.]
Allocate all the controllers, extension I/O units and actuators
and establish the wiring layout by following the instructions
in this manual and an instruction manual of each device.
Power Boot
Connect a PC or teaching pendant, set AUTO/MANU
switches on XSEL-R/S related controllers to [MANU]
position, and then turn the power ON.
No.ψ Deal with each condition depending on the status
display.
[Refer to the instruction manual of XSEL-R/S
related controller product.]
Program creation
Create a program by operating the teaching tool
such as PC.
Check Item
Is the status display on the front panel of
XSEL-R/S related controllers showing “rdy”?
Program Check 2
By operating the teaching tool such as PC, set the
safety speed invalid and check the program
operations in one line to another.
Program Check 1
By operating the teaching tool such as PC, set the
safety speed valid and execute the program in 1
line to another to check the operation.
Operation Check
Set AUTO/MANU switches on XSEL-R/S related controllers
to [AUTO] position and check the operation by the system.
Parameter Setting
[Refer to Section 3.1 and 3.2]
Establish the parameter settings of the XSEL-R/S
related controllers by operating the teaching tool
such as PC.
No.ψ
Check Item
Is the status display on the front panel of main unit
of XSEL-R/S related controllers showing “rdy”?
ω
ω
ω
ω
ω
Deal with each condition depending on the status
display.
[Refer to the instruction manual of XSEL-R/S
related controller product.]
Create the assignment map (assignment map reference
form is attached as appendix) for the shared memory in
advance, and determine the parameter settings.
[Refer to Chapter 3 Operation]
