12. Precautions for Use
12.5 Suction Rate of Clean Room Specification IX-NNC 1205/1505/1805
Cleanness of class 10 can be achieved when air is suctioned at the specified rate from the quick suction joint
provided on the base/rear panel.
x The user must provide the suction device and air tube for suction (‡6).
Suction rate (NR/min)
90
x The clean room must have a down-flow environment.
x Cleanness class 10 corresponds to the particle size of 0.1Pm.
x Dust will be raised if suction is not provided.
Quick suction joint
(Applicable tube: Outer diameter
‡6, inner diameter ‡4)
Caution
