Page 38

background image

32

4. W

iring Diagram

4.3 Cable

Wiring

Table

(1) PG cables (outside robot) DWG No. 1090985*

Robot end

Controller end

Plug

DF3-2EP-2C

(by Hirose Electric)

Plug connector
10126-3000VE
(Sumitomo 3M)

Socket
DF11-6DS-2S
(by Hirose
Electric)

0.12-mm

2

twisted-
pair,
4-core
shielded
cable

Orange 1

red

Orange 1

black

Light gray

1 red

Light gray

1 black

Tube

symbol

Connector

Signal

Pin
No.

Connection

ID No.

Cable

Pin
No.

Connector

Signal

Tube

symbol
