8. External Dimensions

71

8.7.2 Horizontally Oriented Wall Mount Type (Option)

S10SS Horizontally Oriented Wall Mount Type (Option)

No.

st

L

A

B

C

D

Weight (kg)

1

90

430

1

44

8

144

8.9

2

180

520

1

134

8

234

9.7

3

270

610

1

224

8

324

10.6

4

360

700

2

14

12

414

11.4

5

450

790

2

104

12

504

12.3

6

540

880

2

194

12

594

13.1

7

630

970

2

284

12

684

13.9

8

720

1060

3

74

16

774

14.7

9

810

1150

3

164

16

864

15.6

10

900

1240

3

254

16

954

16.4

11

990

1330

4

44

20

1044

17.2

12

1080

1420

4

134

20

1134

18.1

13

1170

1510

4

224

20

1224

18.9

14

1260

1600

5

14

24

1314

19.7

15

1350

1690

5

104

24

1404

20.6

16

1440

1780

5

194

24

1494

21.6

17

1530

1870

5

284

24

1584

22.2

18

1620

1960

6

74

28

1674

23.1

19

1710

2050

6

164

28

1764

23.9

20

1800

2140

6

254

28

1854

24.7

21

1890

2230

7

44

32

1944

25.6

22

1980

2320

7

134

32

2034

26.4

23

2070

2410

7

224

32

2124

27.2

31

54

100

100

20

20

70

10

10

ME

SE

90

5

st

90

5

160

25

50

25

85

195

91

4

100

93

120

119

81

111

106

44

5

4

84

5.5

2.7

1.8

5.8 3.3

70

80

97

+0.012

0

24

15

14 19

19

14

40

49

L(st+340)

4-M6, depth 10

2-φ4H7, depth 10

65±0.02

(Reamer pitch: ±0.02)

(55)

ME (*)

HOME

M3 T-slot

(F)

(55)

Cable

2-φ4H7,

reamed depth 5

2-slot,

depth 5 (G)

C-M5, depth 10

A×150

P

A×150

P

(D)

(B)

Cable track for user

(S type)

Cable track for user

(M type)

Detail view of G

Detail view of F

*The slider goes up the ME in the home-return operation.

Pay attention to interference to peripherals.

ME

: Mechanical end

SE

: Stroke end

Cable Track for User Wiring

Section Dimensions (S type)

Cable Track for User Wiring

Section Dimensions (M type)
