8. External Dimensions

57

8.1.3 Horizontally Oriented Wall Mount Type (Cable Track Opposite Type)

(Option)

S6SS Horizontally Oriented Wall Mount Type (Cable Track Opposite Type) (Option)

No.

st

L

A

B

C

D

Weight (kg)

1

48

334

1

28

8

128

3.6

2

96

382

1

76

8

176

3.8

3

144

430

1

124

8

224

4.0

4

192

478

1

172

8

272

4.2

5

240

526

2

20

12

320

4.4

6

288

574

2

68

12

368

4.6

7

336

622

2

116

12

416

4.8

8

384

670

2

164

12

464

5.0

9

432

718

3

12

16

512

5.2

10

480

766

3

60

16

560

5.5

11

528

814

3

108

16

608

5.7

12

576

862

3

156

16

656

5.9

13

624

910

3

204

16

704

6.1

14

672

958

4

52

20

752

6.3

15

720

1006

4

100

20

800

6.5

16

768

1054

4

148

20

848

6.7

17

816

1102

4

196

20

896

6.9

18

864

1150

5

44

24

944

7.1

19

912

1198

5

92

24

992

7.3

20

960

1246

5

140

24

1040

7.5

21

1008

1294

5

188

24

1088

7.8

22

1056

1342

6

36

28

1136

8.0

23

1104

1390

6

84

28

1184

8.2

24

1152

1438

6

132

28

1232

8.4

25

1200

1486

6

180

28

1280

8.6

26

1248

1534

7

28

32

1328

8.8

24

15

14 19

19

14

40

49

1

24

5.5

2.7

1.8

5.8 3.3

60

ME

SE

155

90

89

51

91

4

60 54

81.5

76.5

43

(35)

5

5

63

63

st

84

4

*The slider goes up the ME in the home-return operation.

Pay attention to interference to peripherals.

ME

: Mechanical end

SE

: Stroke end

Cable track for user

(M type)

Cable track for user

(S type)

Detail view of G

Detail view of F

+0.01

0

3

M3 T-slot

(F)

Cable Track for User Wiring

Section Dimensions (S type)

Cable Track for User Wiring

Section Dimensions (M type)

Cable

35

50

(B)

50

30

A×100

P

A×100

P

2-φ3H7,

reamed depth 3

2-slot,

depth 3 (G)

C-M4, depth 10

D

L(st+286)

160

50

80

25

8

8

37

65±0.02

4-M4, depth 10

2-φ4H7, depth 8

(Reamer pitch: ±0.02)

45

25

ME (*)

(35)

HOME
