1. Specifications Check

20

1.3.2 Availability Judgment for each Operational Condition

[1] Condition 1 Judgment of Thrust Necessary for Acceleration

For the slider to accelerate according to a command, the thrust required for acceleration, or Fa,

must be smaller than the maximum thrust of the shaft-type linear servo actuator.

Fa = (M + m) • a + Ft

Here,

M : Slider weight (kg)

m : Slider payload (kg)

a : Commanded acceleration (m/s

2

)* *1G = 9.8m/s

2

Ff : Traveling resistance (N)

In the case of a shaft-type linear servo actuator, the traveling resistance is determined by the

speed and empirically calculated as specified below.

[Traveling resistance]

The table below lists the traveling resistance of each model.

Traveling resistance Ff (N)

S6SS, S6SM

5V + 5

S8SS, S8SM

9V + 7

S8HS, S8HM

9V + 7

S10SS, S10SM

20V + 13.5

S10HS, S10HM

20V + 13.5

If the obtained Fa is smaller than the maximum thrust of the shaft-type linear servo actuator,

condition 1 is satisfied.

Maximum thrust (N)

S6SS, S6SM

60

S8SS, S8SM

100

S8HS, S8HM

140

S10SS, S10SM

260

S10HS, S10HM

320

[Slider weight]

S6SS, S6SM

: 1.4kg

S8SS, S8SM

: 1.7kg

S8HS, S8HM

: 2.0kg

S10SS, S10SM

: 3.5kg

S10HS, S10HM

: 4.0kg

V: Slider speed (m/s)

(Achieved speed is used in

a triangle wave operation.)
