1. Specifications Check

13

1.1.4 How to Read the Model Number

L S A - S 6 S S - I - 1 0 0 - 4 8 - T 2 - P - C T 2 - * *

Note 1 It may be displayed for IAI use. It is not a code to show the model type.

Series Name

Shaft Type

S6SS:

width 60mm Single Slider

S6SM:

width 60mm Double Slider

S8SS:

width 80mm Single Slider

S8SM:

width 80mm Double Slider

S8HS:

width 80mm High-Thrust

Single Slider

S8HM:

width 80mm High-Thrust

Double Slider

S10SS:

width 100mm Single Slider

S10SM:

width 100mm Double Slider

S10HS:

width 100mm High-Thrust

Single Slider

S10HM:

width 100mm High-Thrust

Double Slider

I: Incremental

100: 100W

200: 200W

200S: 200W

Identification for IAI use only

(Note1)

None:

Cable Track

Attachment Orientation�

(Standard Equipment)

CT2 to 6�

Cable Track

Attachment Orientations 2 to 6

US1 to 6�

Cable Track for User S type

Attachment Orientations 1 to 6

UM1 to 6�

Cable Track for User M type

Attachment Orientations 1 to 6

N : None

P : 1m

S : 3m

M : 5m

X�� : Length Specification

T2 : SCON

: SSEL

: XSEL-P/Q

[Refer to 1.2 “Specifications”]
