[Function] Output the value of variable 99 to ourput ports or flags from operand 1 to operand 2.
Note 1: The maximum number of digits that can be output is 8 (32 bits).
Note 2: The output port • f lag used is 4 x n (number of digits).
.
[Example 1] OUT 300 2 Write the value of variable 99 as a BCD value to output ports from 300
for 2 digits (up to 307).
[Example 2] LET 1 300 Assign 300 to variable 1.
LET 2 2 Assign 2 to variable 2.
OUT *1 *2 Write the value of variable 99 as a BCD value to output ports from 300
(content of variable 1) for 2 digits (content of variable 2) (up to 15).
n o i s n a p x E
n o it i d n o c
) R O · D N A (
t u p n I
n o it i d n o c
) g a l F · O /I (
d n a m m o C
t s o P
) g a l F · t u p t u O (
d n a m m o C 1 d n a r e p O 2 d n a r e p O
l a n o it p O l a n o it p O B T U O g a l F · O /I s t i g i d D C B f o . o N
85 • • • • • • • • • • • • • • • • Variable 99
r e p p U r e w o L
1 0 0 0 0 1 0 1 • • • Binary number
ò
12. SEL Language
● OUTB (BCD Output)
• • • Output port Number
ON OFF OFF OFF OFF OFF ON ON
307 306 305 304 303 302 301 300
