17
7.2 Axis Pattern
Selection of an axis is specified by either "1" or "0"
Axis No. 8 7 6 5 4 3 2 1
Used 1 1 1 1 1 1 1 1
Not Used 0 0 0 0 0 0 0 0
Example
If Axis 1 and Axis 8 are in use, then this is signified by...
1 0 0 0 0 0 0 1
The zeroes before the 1 are unnecessary. The simplified form is 11, without leading zeroes.
In this example, the zeroes are necessary in order to indicate the position of Axis 8.
Axis pattern is used when designating more than one axis at the same time.
Axis pattern designation command
OFST, GRP, SVON, SVOF, HOME, JFWN, JFWF, JBWN, JBWF, STOP, PTST, PRED
Axis 8 Axis 1
Axis 2 Axis 1
Example
If Axis 1 and Axis 2 are in use, then this is signified by...
0 0 0 0 0 0 1 1
7. Axis Designation
(Upper) (Lower)
Note: The axis pattern for the DS type is preset since there is only one axis.
