6. Installation
38
2-‡8H7, depth 10
8-M8, depth 20 8-M8, depth 20 2-‡8H7, depth 10
051
20.0
75
8
30 90 30
15 120 15
150
051
051
20.0
90
8
45 90 45
10 160 10
180
051
z ISB, ISPB: Medium type MXM/MXL/MXMX
MXM/MXMX slider MXL slider
Tightening torque
Installation bolt
Bolt seating surface is steel Bolt seating surface is aluminum
M6 12.3 Nxm 5.4 Nxm
M8 30.0 Nxm 11.5 Nxm
(Note) When using positioning holes, use pins with an engagement tolerance of h7 or equivalent.
z ISB, ISPB: Large type LXM/LXL/LXMX/LXUWX
LXM/LXMX/LXUWX slider LXL slider
Tightening torque
Installation bolt Bolt seating surface is steel Bolt seating surface is aluminum
M8 30.0 Nxm 11.5 Nxm
(Note) When using positioning holes, use pins with an engagement tolerance of h7 or equivalent.
2-‡8H7, depth 10
4-M6, depth 18
4-M8, depth 18
4-M8, depth 18
2-‡8H7, depth 10
