Evolver 303 Dual Purge Robotic Atomizers - Parts Identification
79138-00
Complete Head Assembly
1
2
2
3
79153-65R-1
Air Cap
1
2
3
4
79196-98-1, 79197-63-1
(Optional Air Caps)
79140-02
Fluid Tip
1
2
3
4
01=.042,03=.070
(Optional Fluid Tips)
70430-01
Electrode
1
2
3
4
79142-00
Screw
2
2
4
4
79171-00
Spring, Connector
2
2
4
4
79141-00
Plug, Connection
2
2
4
4
14061-09
Conductive Foam
1
1
2
2
79144-00
Shaft, Air Valve
1
1
2
2
79143-00
Bushing, Air Valve
1
1
2
2
79173-00
Block, Locking
2
2
4
4
79174-00
Screw
1
1
2
2
77367-00
Seat Assembly
1
1
2
2
Part #
SERVICE PARTS
Description
1-2
3-4 5-6 7-8
Notes
Number of Applicators
Petroleum Jelly Lubricant for all O-Rings
Thread Sealant (Blue), Loctite 24077
Thread Sealant (White), Loctite 59231, Paste
Thread Sealant (Purple), Loctite 22221
LUBRICANTS AND SEALERS
A11545-00
7969-03
7969-10
7969-05
Part #
Description
AA-08-01.1
