Evolver 303 Dual Purge Robotic Atomizers - Introduction

8

EVOLVER 303 DUAL PURGE APPLICATOR ASSEMBLY

Head Configuration

0 = 60

° Single-Head

1 = 90

° Single-Head

2 = 60

° Dual-Head

3 = 90

° Dual-Head

Body Style

0 = For Highly Resistive Materials (Clear Coat)

1 = For Conductive Materials (Base / Clear)

2 = For Highly Conductive Materials (Base / Clear)

Atomization Technology

0 = Conventional Spray / Non-Bleed

1 = HVLP Spray / Non-Bleed

4 = Conventional Spray / Bleed

5 = HVLP Spray / Bleed

A12374 - A B C

Tubing Bundle Length

0 = Air Tubing (Not Included)

1 = 4.5m (15-ft.) Long Tubing Assembly

2 = 9m (30-ft.) Long Tubing Assembly

Low Voltage Cable Length

0 0 = Low Voltage Cable Not Included

01 = 15-ft. Low Voltage - Quick Connect to MicroPak

02 = 25-ft. Low Voltage - Quick Connect to MicroPak

03 = 40-ft. Low Voltage - Quick Connect to MicroPak

04 = 50-ft. Low Voltage - Quick Connect to MicroPak

05 = 75-ft. Low Voltage - Quick Connect to MicroPak

A12283 - A BB CC DD

Robot Adapter

00 = Adapter Not Included

01 = Adapter (Fanuc P-155) 78983-00

02 = Adapter (ABB 5400, 5002) 79107-00

03 = Adapter (Fanuc-P200/P-250) 79131-00

04 = Adapter (KAWASAKI-KE610L) A10847-00

05 = Adapter (MOTOMAN-PX2850) A10848-00

06 = Adapter (MOTOMAN-PX2900) A10849-00

07 = Adapter (B & M LZ2000) A10851-00

08 = Adapter (ABB 5400 Enhanced Wrist) A12036-00

Fiber Optic Cable Length

00 = Fiber Optic Cable Not Included

01 = 15-ft. Long Fiber Optic Cable

02 = 25-ft. Long Fiber Optic Cable

03 = 40-ft. Long Fiber Optic Cable

04 = 50-ft. Long Fiber Optic Cable

05 = 75-ft. Long Fiber Optic Cable

06 = 100-ft. Long Fiber Optic Cable

EVOLVER 303 DUAL PURGE TUBING BUNDLE ASSEMBLY (METRIC)

AA-08-01.1
