Evolver 303 Dual Purge Robotic Atomizers - Parts Identification

63

Figure 32: A12375-01 Rear Plate Assembly (Single Purge)

Apply thread sealer 7969-10 to threads prior to assembly.

Apply a thin film of SSL-11 petroleum jelly to o-rings before assembly.

PARTS LIST BULLET DEFINITION TABLE - (Figure 32)

1

2

2

1

A12285-00

Rear Plate Assembly, RMA-303 Single Purge

1

2

79001-07

O-Ring, Solvent Proof

3

3

79001-39

O-Ring, Solvent Proof

3

4

79001-40

O-Ring, Solvent Proof

8

5

SSF-2052

Set Screw, 3/8" Lg X 10-24

2

6

77507-00

Air Stud, Small, Machined

5

7

77505-00

Air Stud, Large

3

8

79001-05

O-Ring, Solvent Proof

5

9

77506-00

Air Stud, Medium, Machined

1

10

79001-06

O-Ring, Solvent Proof

2

11

79001-09

O-Ring, Solvent Proof

1

12

A12035-00

Air Stud, Medium, Machined, Evolver 303

1

13

A11074-00

Plug, Fiber Optic

1

Item #

A12375-01 REAR PLATE ASSEMBLY (SINGLE PURGE) -

PARTS LIST (Figure 32)

Part #

Description

Qty

2

2

2

1

1

2

1

1

1

5

5

7

2

3

6

8

9

10

4

7

2

4

11

6

8

6

8

4

7

2

6

8

6

8

12

10

4

4

3

4

4

4

13

3

2

AA-08-01.1
