Evolver 303 Dual Purge Robotic Atomizers - Parts Identification

For TA line, lengths above 1.8m (6-ft.) require an increase to a minimum of 12mm OD X 10mm ID tubing.

For lengths above 4.6m (15-ft.), the SAI, SAO, and BRK require the next larger nominal size ID tubing.

Apply 7969-03 to threads as required.

Install 76566-24C (Ref.) SHCS into Robot Adapter.

Apply 7969-10 to threads as required.

PARTS LIST BULLET DEFINITION TABLE - (Figure 33)

5

3

2

1

1

4

3

1

A12284-00

Robot Mounting Plate, RMA-303 Dual Purge

1

2

A12209-00

Fitting, 7mm X 10mm X 1/4" BSPT

3

DL1, DL2, TA

3

A12210-00

Tube Fitting, 5mm X 8mm X 1/4" BSPT

2

P1, P2

4

A12213-00

Fitting, Modified, 6mm X 1/8" BSPT, Push Connect

2

BA, BRK

5

77544-01

Male Connector, 4mm ODT X 10-32 Thd.

6

P1D, P2D, P1T, P2T,

SOL/RP, BA RTN

6

A11063-00

Insert

4

DL1, DL2, P1.IN,

P2. IN

7

A10891-03

Fitting, 1/4" BSP X 8mm ODT, Straight

2

SAI/AA, SAO/FA

8

77545-12

Cap, 5/32" OD Tube, Yellow Identification

1

BA RTN

9

77545-03

Cap, 5/32" OD Tube, Green Identification

1

P1T

10

77545-01

Cap, 5/32" OD Tube, Blue Identification

1

ST/RP

11

77545-11

Cap, 5/32" OD Tube, Gray Identification

1

P1D

12

77545-04

Cap, 5/32" OD Tube, Clear Identification

1

P2T

13

77545-02

Cap, 5/32" OD Tube, Black Identification

1

P2D

14

SSF-2052

Set Screw, 3/8" Lg. X 10-24

2

15

76566-24C

Screw, Stainless, 1/4-20 X 3/4" Lg. SHCS

6

16

Table J - "M"

Robot Adapter

1

17

A12212-00

Fitting, 6mm X 4mm X 1/8" BSPT

2

SOL, CW

18

A12239-00

Low Voltage Cable, Quick Disconnect

1

LV

19

Table H - "J"

Low Voltage Cable Assembly

Table H - "K"

20

76698-02

Tubing, PFA, 5/16" OD X 3/16" ID

Table G - "I"

P1.IN, P2.IN

21

77536-07

Tube, 4mm OD X 2.7mm ID, Yellow

Table G - "I"

BA RTN

22

77535-01

Tube, 4mm OD X 2.7mm ID, Black

Table G - "I"

P2D

23

77536-03

Tube, 4mm OD X 2.7mm ID, Green

Table G - "I"

P1T

24

77536-04

Tube, 4mm OD X 2.7mm ID, Blue

Table G - "I"

ST/RP

25

77535-05

Tube, 4mm OD X 2.7mm ID, Natural

Table G - "I"

P2T

26

A10893-07

Tube, 8mm OD X 6mm ID, Blue

Table G - "I"

SAI/AA

27

A10840-08

Tube, 6mm OD X 4mm ID, Yellow

Table G - "I"

BA/PT

28

A10840-09

Tube, 6mm OD X 4mm ID, Orange

Table G - "I"

BRK

29

A10841-03

Tubing, PFA, 6mm OD X 4mm ID

Table G - "I"

SOL, CW

30

A10893-04

Tube, 8mm OD X 6mm ID, Gray

Table G - "I"

SAO/FA

31

77536-06

Tube, 4mm OD X 2.7mm ID, Silver

Table G - "I"

P1D

32

A12211-00

Tubing, Nylon, 10mm OD X 7mm ID, Natural

Table G - "I"

DL1, DL2

33

A12211-00

Tubing, Nylon, 10mm OD X 7mm ID, Natural

1.8m (6 Ft.)

TA

34

Table I - "L"

Fiber Optic Cable

1

FO

Item #

A12283-XXXXXXX TUBING BUNDLE ASSEMBLY (METRIC) -

PARTS LIST (Figure 33)

Part #

Description

Qty

1

1

2

4

4

5

3

Port

Location

4

AA-08-01.1
