20
Evolver 303 Dual Purge Robotic Atomizers - Installation
Tubing Material Tubing Size
B.A/P.T Bearing Air (Paint Trigger) Yellow Nylon 6mm OD X 4mm ID
B.A RTN Bearing Air Return Yellow Nylon 4mm OD X 2.7mm ID
BRK Brake Air Orange Nylon 6mm OD X 4mm ID
DL1/DL2 Dump Line Natural 10mm OD X 7mm ID
F.O Fiber Optic Cable Natural Polyethylene 1/4" OD (jacket)
LV Low Voltage Cable Black N/A N/A
P1.IN/P2.IN Paint In Natural 5/16" OD X 3/16" ID
P1T Paint 1 Trigger Green Nylon 4mm OD X 2.7mm ID
P2T Paint 2 Trigger Natural Nylon 4mm OD X 2.7mm ID
P1D Paint 1 Dump Trigger Silver Nylon 4mm OD X 2.7mm ID
P2D Paint 2 Dump Trigger Black Nylon 4mm OD X 2.7mm ID
SA.I/A.A Inner Shaping Air (Atom. Air) Blue Nylon 8mm OD X 6mm ID
SOL Solvent In Natural 6mm OD X 4mm ID
SA.O/F.A Outer Shape Air (Fan Air) Gray Nylon 8mm OD X 6mm ID
ST/RP Solvent Trigger Signal Blue Nylon 4mm OD X 2.7mm ID
T.A Turbine Air Natural Nylon 10mm OD X 7mm ID
SIGNAL IDENTIFICATION TABLE BELLS (APPLICATORS)
Abbr. Description Color
AA-08-01.1
