Evolver 303 Dual Purge Robotic Atomizers - Maintenance

SERVICE

Because we want to provide our users with the most

up-to-date technology possible, we are constantly

seeking to improve products. If a change in product

configuration occurs after it is on the market, we will

implement that technology in future production and,

if practical, make it available to current users. The

following service information is based on standard

specifications and procedures for this product. If you

find some minor deviations between this information

and your equipment because of design or manufac-

turing changes, contact your Ransburg representative

to resolve the difference.

>

As the spray head is removed from the valve

manifold assembly, a certain amount of residual

fluid may be present. Care must be taken not

to allow this fluid to drain into the high voltage

terminal rings or air passages.

>

Eye protection should be worn while servic-

ing applicator.

W A R N I N G

!

C A U T I O N

!

>

An electrical discharge or spark may create an

electrical and/or fire hazard during maintenance.

Do not service the spray applicator with the

power supply on. Verify that the power supply

on/off switch has been turned off.

>

Unexpected robot movement can be hazard-

ous. Do not adjust or repair the spray applicator

when the robot is operating or waiting to start.

The robot must be locked out and tagged out

per OSHA prior to removing the applicator from

the robot manifold assembly.

W A R N I N G

!

Before performing any work on the spray applicator,

always flush the fluid passages, blow dry with push-

out air, and wipe the spray applicator clean. Refer to

"Applicator Cleaning" in the "Maintenance" section

for instructions on how to properly clean the spray

applicator. Depressurize all fluid and air passages

before removing the applicator from its manifold.

Always work in a clear, clean space to minimize part

loss and damage.

SPRAY HEAD ASSEMBLY

>

Disassemble the spray head only

enough to remove and replace defective

parts. For instance, if only replacing the

front electrode it is not necessary to remove

the fluid nozzle.

NOTE

>

At assembly, apply a small amount of

dielectric grease to grooves in spray head

and valve manifold to reduce high voltage

breakdown. Excessive grease will not allow

spray head [5] to seat fully against mounting

block assembly [3] (see Figure 15).

>

To prevent damage, always lubricate

the o-rings located on the underside of the

spray head.

NOTE

AA-08-01.1
