Ransburg Evolver 303 Dual Purge Solvent Robotic Applicator A12374-XXX User Manual
Page 44
Figure 14: 79138 Evolver 303 Dual Purge Applicator Head Assembly
39
Evolver 303 Dual Purge Robotic Atomizers - Maintenance
22
24
23
11
13
25
17
15
15
16
TORQUE TO 30-35 IN/LBS
8
7
9
LOCATED INSIDE 13
10
18
LOCATED INSIDE 17
15
14
12
19
AIR VALVE SHAFT FLATS
B
ALIGNMENT TABS
ALIGN TAB ON AIR VALVE BUSHING (14) INTO GROOVE OF BODY
ALIGN TAB
AA-08-01.1
