Evolver 303 Dual Purge Robotic Atomizers - Introduction

6

The Evolver 303 Dual Purge Spray Applicator System

consists of four major components:

1. Quick-Disconnect Spray Head

2. Applicator Head Mounting Block Assembly

3. Valve Manifold Assembly (Includes the High

Voltage Cascade with a Quick-Disconnect

Ring)

4. Rear Tubing Manifold Assembly (both English

and Metric)

The spray head(s) and valve manifold contain the

fluid, air, and high voltage passages. All fluid

passages contain stainless steel and/or nylon fittings,

compatible with halogenated hydrocarbon solvents.

The robot manifold incorporates stainless steel fluid

connections.

The high voltage cascade is entirely encapsulated

with a solvent resistant epoxy. This cascade generates

voltages up to 100kV fed by a low voltage cable.

There are three sources for the high voltage supply

to the Evolver 303 Dual Purge Applicators:

• MicroPak™ Control Unit (LECU5004)

• Stand-alone control/power supply unit

(A10406)

• MicroPak

TM

Control Unit (LECU5004-31)

The MicroPak Power Supply control unit provides a

low voltage signal through the robot manifold to the

spray applicator. The high voltage cascade located

within the applicator converts the low voltage DC

signal to a high voltage electrostatic output.

For applications that have the ability to control fan

and atomization air remotely, the bleed style head

is available.

NOTES

AA-08-01.1
