37

Evolver 303 Dual Purge Robotic Atomizers - Maintenance

Air Valve Removal

(See Figure 14)

1. After removal of end cap and spring, the air valve

[10] can be pulled straight out the back of the head

assembly.

2. Inspect and replace the u-cup [8], if necessary, by

holding the air valve shaft [10] on it's flats and loosen-

ing the piston nut [7] counter-clockwise.

3. Remove the seal carrier [17] with seal removal

tool [B].

4. Use a bent hook to reach inside the air valve

bushing [14], grip slot and pull out. Use the same

procedure to pull out the rear seal carrier [17].

>

Use Caution as NOT TO scratch or raise burrs

on inside diameters of the parts.

C A U T I O N

!

12. If the locking tab plug connection [24] needs

to be replaced, first remove the electrode spring

connector [23] by pulling straight out with a needle

nose pliers. If removed, the spring wire should be

replaced.

13. Remove socket head screw [22] and connec-

tion plug [24] from body.

14. Replace conductive compressable contact [25]

if necessary.

15. Reinstall the connection plug [24] into the body,

making sure the tabs on the bottom align

with

the notches in the body [19].

16. Insert and tighten the screw [22], making sure

the tabs remain inside the notches [24] in the body.

17. Insert the spring electrode wire [23] through

the hole in the screw using a needle nose pliers

on the straight wire portion. Carefully rotate and

push the wire through the screw hole and into the

compressable contact until the spring contacts the

screw head.

5. Remove and replace all o-rings if necessary.

6. O-rings [12] and [18] must be installed inside

their mating parts (see Figure 14).

7. The o-ring [16] should be inserted into

the front of the bushing [14] and one of the o-rings

[15] installed onto the outside groove before the

bushing is installed.

8. Reassemble the remaining parts as shown in

Figure 14 making sure that the alignment tab on

the bushing [14] lines up with the align groove in

the body [19].

9. Torque the seal carriage [13] to 30-35 lbs•in (4.0-

4.5 Nm).

10. If the u-cup needs to be replaced, assemble

on piston plate [9] and push both onto shaft, tighten

securely with piston nut [7] and install in body as

one assembly.

11. Assemble the remainder of the applicator head

as stated earlier.

AA-08-01.1
