Ransburg Evolver 303 Dual Purge Solvent Robotic Applicator A12374-XXX User Manual
Page 26
21
Evolver 303 Dual Purge Robotic Atomizers - Installation
Figure 9: Applicator and Manifold Assembly
1
A12283-XXXXXXX
Tubing Bundle Assembly (Metric)
1
2
A12374-XXX
Evolver 303 Dual Purge Spray Applicator Assembly
1
3
76566-24C
Screw, 1/4-20 X 3/4" Lg., SHCS
6
4
See Table 1
Robot Adapter
1
Item #
APPLICATOR AND MANIFOLD ASSEMBLY - PARTS LIST
(Figure 9)
Part #
Description
Qty
3
1
2
4
AA-08-01.1
