26

Evolver 303 Dual Purge Robotic Atomizers - Operation

>

Most paints and solvents, including those

listed in "Polar and Non-Polar Solvents Chart" in

the "Maintenance" section, are toxic to a certain

degree and flammable or combustible. Use

them only in a well ventilated atmosphere. Use

protective equipment as required in the Material

Safety Data Sheet supplied with the substance.

W A R N I N G

!

>

For HVLP operation (max. 10 psi, 0.7

bar cap pressure), DO NOT exceed the air

inlet pressure, which was read at the gun

base before the tubing manifolds, given

as follows:

PSI

(Bar) CAP #

42

(2.9)

48-1

42

(2.9)

481-1

NOTE

FLUID VALVE CONTROLS

Trigger and Dump(See Figure 12)

The fluid valves in the Evolver 303 dual purge are actu-

ated by an air signal. The air pressure must exceed 70

psi (4.8 bar) to assure proper actuation of the valve.

Applying air to the valve actuator turns on the fluid

flow for the valve.

The paint trigger valve controls the paint flow to

the applicator. When actuated, paint flows through

the valve to the coiled fluid tube and into the spray

head.

The dump valve controls the paint flow through the

dump line. When actuated, paint flow is directed

to the dump return line. This provides a method of

rapidly removing paint from the incoming line for

cleaning and/or color change. Normally, the dump

valve is not actuated at the same time as the paint

valve since the paint valve is intended to cause the

fluid to flow to the applicator head at the prescribed

input pressure.

DUAL PURGE SPRAYING

The Evolver 303 dual purge has true dual purge

capability. This means the applicator can continue

to spray paint, at voltage, while side "B" or "Paint 2"

is being flushed or cleaned. To operate in the dual

purge mode, two (2) separate color valve systems

must be installed. This applicator should be used

with the MCV Dual Purge Color Changer.

When the target part is finished and a color change is

desired, voltage does not need to be turned off. When

finished spraying with color "A", shut off color "A" (P1.

IN/P2/IN). Trigger on the solvent (SOL), and acuate

the applicator. This will clean the coiled fluid tube

and applicator spray head, by pushing the remaining

paint out the front of the applicator. Next, load color

"B" (P1.IN/P2.IN) and begin spraying with color "B".

While continuing to spray color "B", open the dump

line corresponding to the line color "A" is in (DL1/DL2)

to flush color "A" through the dump line.

When the cleaning cycle with solvent is complete,

an air purge for several seconds is recommended to

clean and dry the ID of the dump line hose.

Paint Viscosity

The applicator is capable of atomizing paint of most

any desired viscosity, however, it is recommended to

keep the material viscosity as low as possible. This

allows spraying at lower fan and atomization air

pressures which result in less overspray and higher

transfer efficiency.

Fluid Flow Rate

Fluid flow is adjusted through the robot PLC by varying

the pilot pressure to an exterior fluid regulator. Fluid

pressures from the circulating system may exceed

the maximum fluid pressure rating of the Evolver

303 dual purge applicator. Because of these high

fluid pressures, a manual step-down fluid regulator

must be used.

Applicator Trigger Control Air

The Evolver 303 dual purge applicators require a

minimum of 70 psig trigger control air pressure to

ensure proper operation of the applicator piston.

AA-08-01.1
