25

Evolver 303 Dual Purge Robotic Atomizers - Operation

OPERATION

As with any spray finishing system, operation of the

Evolver 303 dual purge involves properly setting

the operating parameters to obtain the best finish

quality for the coating material being sprayed, while

maintaining correct operation and reliability of the

equipment used. Adjustments to operating param-

eters, which cover spraying, cleaning, and on/off

control, include the following:

• Coating Materials

• Fluid Flow Rate Control

• Fluid Valve / Trigger Control

• Atomization Air

(Paint Atomization Control)

• Fan Air (Pattern Control)

• Electrostatic Voltage

• Target Distance

SPRAY APPLICATOR CONTROLS

Atomization Air (SAI/AA) / Fan Air

(SAO/F.A)

The atomization and fan air are turned on by the

trigger line and are controlled by an internal air valve

located in the applicator head. During normal op-

eration with applicator triggered off, there is a slight

bleed of air through the atomization port.

Atomizing Air

Adjustments are made through the robot PLC or a

manually adjustable air regulator. The lowest air

pressure required to break up the paint should be

used. Lower atomizing air pressures result in less

overspray and increased transfer efficiency.

Fan Air

Adjusting the fan air increases or decreases the size

of the spray pattern. Increasing pressure increases

pattern size. Pattern adjustment should be made to

suit the size and shape of the object being painted.

This adjustment is made through the robot PLC or a

manually adjustable air regulator.

Air cap atomization and fan pressures should be set

and recorded using an air cap test kit. This provides

a consistent measurement, so initial settings may

be duplicated at any time. (See "Accessories" in the

"Parts Identification" section.)

HVLP SPRAY

The Evolver 303 dual purge HVLP models, when

properly set-up, are designed to provide maximum

transfer efficiency by limiting air cap pressures to 10

psi (0.7 bar) (in the U.S., this complies with rules issued

by SCAQMD and other air quality authorities). Air

cap pressures should be measured with an optional

air cap test kit. (See "Accessories" in the "Parts Iden-

tification" section.)

>

Electrical discharge of a high electrical ca-

pacitance fluid/paint system can cause fire or

explosion with some materials. If arcing occurs

when a specific coating material is used, turn the

system off and verify that the fluid is non-flam-

mable. In these conditions, the system is capable

of releasing sufficient electrical and thermal

energy to cause ignition of specific hazardous

materials in the air.

W A R N I N G

!

>

Operators must be fully trained in safe opera-

tion of electrostatic equipment. Operators must

read all instructions and safety precautions prior

to using this equipment (see NFPA-33).

W A R N I N G

!

AA-08-01.1
