Repair kits – Ransburg Evolver 303 Dual Purge Solvent Robotic Applicator A12374-XXX User Manual
Page 79
74
Evolver 303 Dual Purge Robotic Atomizers - Parts Identification
A10410
Spray Head Mounting Seal 1
2
3
4
Includes:
O-Ring Kit
1 ea. - 79001-04 O-Ring
(Solvent Proof)
2 ea. - 79001-06 O-Ring
(Solvent Proof)
1 ea. - 79001-05 O-Ring
(Solvent Proof)
A10411
Spray Head Repair Kit
1
2
3
4
Includes:
1 ea. - 79151-00 Needle Shaft
1 ea. - 7723-06 Piston, U-Cup
1 ea. - 79001-28 O-Ring
(Solvent Proof)
1 ea. - 79001-29 O-Ring
(Solvent Proof)
3 ea. - 79001-01 O-Ring
(Solvent Proof)
1 ea. - 13076-13 O-Ring
1 ea. - 79001-06 O-Ring
(Solvent Proof)
1 ea. - RME-38 Spring
1 ea. - RME-32 Seal
1 ea. - 79001-01 O-Ring
(Solvent Proof)
1 ea. - 79001-04 O-Ring
(Solvent Proof)
2 ea. - 79001-06 O-Ring
(Solvent Proof)
1 ea. - 79001-05 O-Ring
(Solvent Proof)
2 ea. - 14061-09 Conductive
Foam
1 ea. - 79171-00 Contact Spring
Part #
REPAIR KITS
Description
1-2 3-4 5-6 7-8
Notes
Number of Applicators
AA-08-01.1
