Ransburg Evolver 303 Dual Purge Solvent Robotic Applicator A12374-XXX - Manual (Page 12)

Output Voltage: 30-100kV
Output Range: 0-85 µA
Paint Flow Rate: Variable to 1500 cc/min.
(Depending on viscosity and configuration)
Trigger Response
Time: 134ms Open
318ms Closed
Operating Air Pressures
Atomizing Air: 100 psig (6.9 bar)
max.
Fan Air: 100 psig (6.9 bar)
max.
Trigger Pilot: 70 psig min./100
psig
(4.8 - 6.9 bar) max.
Dump Pilot: 70 psig min./
100 psig max.
(4.8 - 6.9 bar)
Operating Fluid
Pressure: 200 psig
(13.8 bar) max.
100 psig
(6.9 bar) max.
Regulated (with
on-board regulator)
Robot/Mounting Compatibility:
All hollow wrist robots
Applicator Control Unit:
MicroPak Control Unit - LECU5004-31
Stand-Alone Control Unit - A10406
Operating Temperature
Range: 55 °F (12.8°C) - 131°F (55°C)
Approximate Weight
Single-Headed:
60 ° 9.02 lb. (4.1 Kg)
90 ° 8.71 lb. (3.9 Kg)
Dual-Headed:
60 ° 10.91 lb. (4.9 Kg)
90 ° 10.76 lb. (4.9 Kg)
Manifold:
A12373-XX 6.82 lb. (3.1 Kg)
(No tubing or cable)
Length
Single-Headed:
60 ° 16.5-inch (41.9 cm)
90 ° 13.6-inch (34.5 cm)
Dual-Headed:
60 ° 15.8-inch (40.1 cm)
90 ° 12.4-inch (31.5 cm)
Tubing Manifolds (Metric):
A12283-0XXXXXX Air Tubing not
included
A12283-1XXXXXX 4 1/2m (15-ft.)
A12283-2XXXXXX 9m (30-ft.)
SPECIFICATIONS
Atomizing Air
Fan Air
Trigger Air
Dump Pilot
Fluid:
Dump:
Robot Manifold Tubing
Requirements
Tubing Bundle
Metric
8mm OD Nylon
8mm OD Nylon
6mm OD Nylon
4mm OD Nylon
8mm OD
(Non-Shielded)
7mm ID
Environmental/Physical Electrical Requirements
7
Evolver 303 Dual Purge Robotic Atomizers - Introduction
AA-08-01.1
