A760 User Guide: Programming Supplement
Chapter 4: Programming commands
89 Revision F January 2010
Slip paper status (n = 3 or n = 51)
Value of byte Slip Status
returned
0 There is no more printing space on the
current slip, or the slip paper is not
selected.
1 to 8 Remaining print area on the current slip,
in number of lines, at the currently set
line spacing, when the trailing edge
sensor has become uncovered.
Until the trailing edge sensor becomes
uncovered the value reported will be 6,
because there are at least 9 lines
remaining.
Flash memory user sector status (n = 4 or n = 52)
Bit Off/On Hex Decimal Status for transmit status
0 – – – Undefined. Fixed to off.
1 – – – Undefined. Fixed to off.
2 Off 00 0 User data storage write
successful
On 04 4 User data storage write
failed, specified area not
erased.
3 Off 00 0 Flash logo area
adequate,
definition stored.
On 08 8 Flash logo area not
adequate for recent
definition.
4 Off 00 0 Not used. Fixed to off.
5 Off 00 00 No thermal user-defined
characters written to
flash.
On 20 32 Thermal user-defined
characters written to
flash.
6 Off 00 0 No impact user-defined
characters written to
flash.
On 04 64 Impact user-defined
characters written to
flash.
7 – – – Undefined.
Send printer software version
ASCII AX V
Hexadecimal 1F 56
Decimal
31 86
The printer returns 8 bytes containing the boot and flash
software version. The first 4 bytes returned are an ASCII
string for the boot version. The second 4 bytes are an ASCII string for the flash
version. Example: For 1.234.56 (8 bytes), the boot version
is 1.23 and the flash version is 4.56.
