A760 User Guide: Programming Supplement
Chapter 4: Programming commands 82 Revision F January 2010
Transmit peripheral device status (RS-232C printers only)
ASCII ESC u 0
Hexadecimal 1B 75 0
Decimal
27 117 0
Value of returned byte:
Bit 0 Bit 1
1 = Drawer 1 Closed 1 = Drawer 2 Closed
0 = Drawer 1 Open 0 = Drawer 2 Open
Bits 2–7 are not used.
Transmits current status of the cash drawers. One byte
is sent to the host computer. In DTR/DSR protocol,
the printer waits for DSR = SPACE. If a drawer is not
connected, the status will indicate it is closed.
Exceptions
Unlike the A756, that had a dedicated connector and
resultant dedicated status reporting for each cash drawer,
the A760 has a single connector that shares data reporting
from either cash drawer. When either cash drawer is open,
an open status is reported by the printer.
Request alternate status (parallel only)
ASCII ESC u n
Hexadecimal 1B 75 n
Decimal
27 117 n
Value and Range of n:
Value of n Function Description
00 Drawer 1 High = Open
Low = Closed or Not
Present
01 Drawer 2 High = Open
Low = Closed or Not
Present
02 Paper Low High = Paper Out
(Not Implemented. Low = Paper Present
Interpreted as
Paper Out.)
03 Paper Out (Default) High = Paper Out
Low = Paper Present
>03 Ignored, No Change Printer Does
Not Stay BUSY 1
1 PAPER EXHAUST LINE is valid to indicate previously
requested status.
This command allows the printer to inform the host
when the data in the buffer has been processed, when the
IEEE 1284 interface is in unidirectional mode. When this
command is send to the printer, the printer goes “Busy”
unit all data which has been sent to the print has been
processed.. The PAPER EXHAUST line shows the status
for the cash drawer or receipt paper as shown in the table.
Status information is limited to what can be sent by the
dedicated lines: BUSY, ACK, PAPER EXHAUST, and
FAULT.
