A760 User Guide: Programming Supplement
Chapter 4: Programming commands 102 Revision F January 2010
Set GS1 DataBar (RSS) parameters
Setting of parameters for RSS barcode
ASCII GS q a b c d e fL fH
Hexadecimal 1D 71 a b c d e fL fH
Decimal
29 113 a b c d e fL fH
a byte pixels per minimum unit, default 3, minimum 2, maximum 6 (value a applies
to parameters b, c, d)
b byte X undercut, default 0, can be set 0 to a-1
c byte Y undercut, default 0, can be set 0 to a-1
d byte separator height, default a, can be set a to a*2
e byte segment width, used only by GS1 Expanded and Expanded Stacked,
default 22, must be even number 2 to 22
f word line height, used only by UCC128, default 25, can be set 1 to 500
Note: For GS1 DataBar commands, consult ISO/IEC 24721. For further information, visit www.gs1.org.
Print GS1 DataBar (RSS), data length specified
ASCII GS k m nL nH d1... dn
Hexadecimal 1D 6B m nL nH d1... dn
Decimal 29 107 m nL nH d1... dn
m Type
61 GS1
62 GS1 Truncated
63 GS1 Stacked
64 GS1 Stacked Omnidirectional
65 GS1 Limited
66 GS1 Expanded and Expanded Stacked
67 UPC-A
68 UPC-E
69 EAN-13
6A EAN-8
6B UCC/EAN-128 with CC-A or CC-B
6C UCC/EAN-128 with CC-C
Note: Data length specified 1 to 2436 via integer nH : nL.
