A760 User Guide: Programming Supplement
Chapter 4: Programming commands 100 Revision F January 2010
Print bar code
First Variation Second Variation
ASCII GS k m d1…dk NUL GS k m n d1…dn
Hexadecimal 1D 6B m d1…dk 00 1D 6B m n d1…dn
Decimal 29 107 m d1 dk 0 29 107 m n d1…dn
(0 = End of command)
Selects the bar code type and prints a bar code for the
ASCII characters entered. If the width of the bar code
exceeds one line, the bar code is not printed.
There are two variations to this command. The first
variation uses a NUL character to terminate the string; the
second uses a length byte at the beginning of the string .
The check digit is calculated for UPC and JAN (EAN)
codes if it is not sent from the host computer.
Six-character zero-suppressed UPC-E tags are generated
from full 11 or 12 characters sent from the host computer
according to standard UPC-E rules. Start/stop characters
are added for code 39 if they are not included. Rotated barcodes set with small modules (select bar code
width command 1D 77 n , with n = 1 or 2) and PDF 417
barcodes in any orientation are printed at low speed, for
better readability.
Exceptions
The command is only valid at the beginning of a line.
Illegal data cancels the command.
Values:
First variation: String terminated with NUL character. Length k is not specifiede in command string; it depends on the bar
code being printed.
m Bar code d1...dk length
0 UPC-A 48–57 (ASCII numerals) Fixed length: 11, 12
1 UPC-E 48–57 Fixed length: 11, 12
2 JAN13 (EAN) 48–57 Fixed length: 12, 13
3 JAN8 (EAN) 48–57 Fixed length: 7, 8
4 Code 39 48–57, 65– 90 (ASCII alphabet), 32, 36, 37, Variable length
43, 45, 46, 47 (ASCII special characters)
d1 = dk = 42 (start/stop code is supplied
by printer if necessary)
5 Interleaved 2 of 5 48–57 Variable length (even number)
6 Codabar 65–68, start code 48–57, 36, 43, 45, 46, 47, 58 Variable length
10 PDF 417** 1–255 Variable length, maximum 1000 characters
**This bar code can not be printed on the slip station.
