A760 User Guide: Programming Supplement
Chapter 4: Programming commands 28 Revision F January 2010
Graphics
Code (hexadecimal) Command Page
1B (+*.BMP file) Download BMP logo 62
1B 2A m n1 n2 d1…dn Select bit image mode 63
1B 4C n1 n2 d1. . . dn Select double-density graphics (A756 emulation) 64
1B 59 n1 n2 d1…dn Select double-density graphics 64
1D 23 n Select the current logo (downloaded bit image) 65
1D 2A n1 n2 d1…dn Define downloaded bit image 66
1D 2F m Print downloaded bit image 67
1D 82 n1…n72 Print raster monochrome graphics 67
or …n80
1D 83 n1…n144 Print raster color graphics 68
or …n160
1D 84 m n1 n2 d1…dx Download logo image 69
1D 8B n m o Apply shading to logo 69
1D 8C n m Merge watermark mode 70
1D 86 m Monochrome shade mode 70
1D 87 m Color shade mode 71
1D 89 n m Logo print with color plane swap 71
1D 90 m x y o p q Form and merge real-time surround graphic 72
1D 91 n Save graphics buffer as logo 72
1D 92 n Background logo print mode 73
1D 9A n m o Shade and store logo 73
1D 9B m n Logo print with knife cut 73
1D 99 l m n o Apply margin message mode 74
1D A0 nl nh Set temporary max target speed 74
1F 03 16 f s p/r t Set LogoEZ ® colorization 75
1F 03 17 a m s Set LogoEZ ® attribute mapping 78
1F 04 n Convert 6-dots/mm bitmap to 8-dots/mm bitmap 80
1F 7B n Enable constant speed logos 80
