A760 User Guide: Programming Supplement
Chapter 4: Programming commands
121 Revision F January 2010
Code Description
0 (00h) Successful check flip.
1 (01h) Check/slip not detected by
(at least) outside slip sensor.
2 (02h) Flip sensor is covered when should not be.
Slip stuck in flip mechanism.
3 (03h) Outside slip sensor covered.
Inside slip sensor uncovered.
Slip feed rollers open or slipping on check.
4 (04h) Slip motor times out while running check
backward to uncover the inside slip sensor.
Slip feed roller slipping or check jammed.
5 (05h) Slip motor times out while running check
forward to find trailing edge and measure check
length.
Check is too long or jammed.
6 (06h) Check length less than specified minimum.
Check is to short
7 (07h) Check length more than specified maximum.
Check is too long
8 (08h) Slip motor times out while running check
backwards towards flip mechanism.
Does not require covering/uncovering
sensors.
Code Description
9 (09h) Slip motor times out after flip sensor is
covered.
Check misses flip gate.
10 (0Ah) Slip motor times out while check is being fed
into the flip mechanism (to cover flip sensor)
Check missed being diverted by flip gate or
jammed.
11 (0Bh) Flip motor times out during check being
fed into flip mechanism to cover flip sensor.
12 (0Ch) Slip motor times out while continuing to feed
check farther into flip mechanism to uncover
inside flip sensor.
13 (0Dh) Flip motor times out while continuing to feed
check farther into flip mechanism to uncover
inside slip sensor.
14 (0Eh) Slip motor times out while receiving check out
of flip mechanism to cover inside slip sensor.
15 (0Fh) Flip motor times out while pushing check out
of flip mechanism to cover inside slip sensor.
31 (1Fh) Flip sensor remains covered after check should
be out of flip mechanism.
47 (2Fh) Slip motor times out while running check out
of slip station while waiting for outside slip
sensor to be covered.
