A760 User Guide: Programming Supplement
Chapter 4: Programming commands
85 Revision F January 2010
Transmit printer ID, remote diagnostics extension
ASCII GS I @ n
Hexadecimal 1D 49 40 n
Decimal
29 73 64 n
Values of n: Refer to table
Range of n: 32–255
(not all defined but reserved)
Preforms the remote diagnostic function specified by n.
Eighteen remote diagnostic items are defined: eight printer
ID items and ten printer tally items. Most of the diagnostic
items are maintained in non-volatile memory (NVRAM),
but some are maintained in read-only memory (ROM).
The table that follows describes the variables.
Value of n
ASCII
Hex Dec Remote diagnostic item Function
Space 20 32 Serial #, 10 digit ASCII Write to NVRAM Example, send 14 bytes to printer:
GS I @ 0x20 1234567890
! 21 33 Serial # Write to NVRAM, and print on receipt to verify
Example, send 14 bytes to printer:
GS I @ ! 1234567890 This will print on receipt:
Serial # written: 1234567890
“ 22 34 Serial # Not available, cannot clear serial # item
# 23 35 Serial # Return Serial #, preceded by n to identify Printer
returns 12 bytes in above example: #1234567890
$ 24 36 Class/model #, 15 digit ASCII Write to NVRAM
% 25 37 Class/model # Write to NVRAM, and print on receipt to verify
‘ 27 39 Class/model # Return Class/model #, returns 17 bytes
+ 2B 43 Boot firmware part #, 12 digit ASCII Return Boot firmware part #, returns 14 bytes
/ 2F 47 Boot firmware CRC, 4 digit ASCII Return Boot firmware CRC, returns 6 bytes
3 33 51 Flash firmware part #, 12 digit ASCII Return Flash firmware part #, returns 14 bytes
7 37 55 Flash firmware CRC, 4 digit ASCII Return Flash firmware CRC, returns 6 bytes
Ç 80 128 Receipt lines tally, Write to NVRAM Example, send 12 bytes to printer:
8 digit ASCII numeric, GS I @ Ç00010000 To set receipt lines tally to 10,000
max 99,999,999
ü 81 129 Receipt lines tally Write to NVRAM, and print on receipt to verify
Example, send 12 bytes to printer:
GS I @ ü00010000 This will print on receipt:
Receipt tally written: 10,000
Continued…
The first item group in the table includes an example
of data to send and to receive, Data sent from the host
to write to NVRAM must contain all digits required
by the remote diagnostic item. All data must be ASCII.
The printer returns all ASCII data. It is preceded by the
parameter n to identify the diagnostic item and is followed
by a carriage return (0D) to signify the end of the data.
The command performs the remote diagnostic function
specified by n as described in the following table.
