9-14 DCP Cabling and Administration
________________________________________________________________________________________________
________________________________________________________________________________________________ ________________________________________________________________________________________________
4. Assign the DCP equipment location as Dual Port Data (Proc 051, Word 1). Make the entries as
shown in Figure 9-8, Manager II Administration for DCP Ports (Proc 051, Word 1). The equipment
location shown is only an example.
5. Repeat step 4 for the second DCP equipment location.
ENHANCED MODE - PROCEDURE: 051, WORD: 1
MULTIAPPEARANCE TERMINAL AND DATA MODULE TRANSLATION
TERMINAL EQUIPMENT LOCATION PREFERENCE
1. Module: 0 10. Origination: 2 prime line
2. Cabinet: 1 11. Termination: 0 none
3. Carrier: 1
4. Slot: 18 12. Lock/Unlock Available: _
5. Circuit: 3 13. Keyboard Dialing: 1
14. LWC Global Retrieval: _
TERMINAL OR DATA MODULE TYPE 15. Terminal Alarming: _
6. Terminal Type: 3 dual port data 16. BRI TEI: ___
7. Option: 0 data only
PHYSICAL TYPE
8. Data: 1
9. Display: _
Connected to CC0 ON-LINE ♥ MAJOR MINOR RUN TAPE BUSY OUT IN USE WAIT
enter command: _
3 Data 5 Help 6 Field 7 Input 8 Cmds
Figure 9-8. Manager II Administration for DCP Ports (Proc 051, Word 1)
