TESTING THE SYSTEM
INITIAL TESTING
As the system is initially installed it is recommended
that each device is tested in turn as it is installed, (refer
to testing instructions for particular device).
TESTING AN INSTALLED SYSTEM
The Smart Home Box has a programmed test routine.
You may test the system at any time, however it is
recommended that the system is tested at regular
intervals not exceeding 3 months.
With the system in Disarm Mode
Press ,
User Password
This puts the system into Test Mode.
Use the and buttons to scroll through
the menu and press to select the displayed
test function or sub-menu.
Note: After completing all required test functions, press
to leave Test mode and return to Disarm mode.
WALK TEST
Before commencing testing, please ensure that there is
no movement in any PIR protected area, all
doors/windows protected by Magnetic Contact
Detectors are closed and that all battery covers and
housings are correctly fitted.
Scroll through the top level Test Mode menu until
‘WALK TEST’ is displayed and press .
‘Walk Test Waiting…’ will be displayed.
1. Trigger each detector on the system by either
walking into a PIR protected area or by opening
a door/window protected by a Magnetic Contact
detector. As each detector is triggered the
Smart Home Box will chime to indicate that an
alarm signal has been received and the identity
of the zone that the detector is configured for will
be displayed.
2. Operate detector anti-tamper switches by
opening the case of the device. As the switches
are operated the Smart Home Box will chime and
‘Z01 Tamper’ will be displayed.
3. Activate each button on the Remote Control in
turn, the Smart Home Box will chime and display
the message as following:
Button Pressed Message Display
Disarm ‘R01 Disarm’
Night Arm ‘R01 Night Arm’
Fully Arm ‘R01 Fully Arm’
Panic Switch ‘R01 Panic’
4. If PIR Detector is in low battery status, the Smart
Home Box will chime and ‘Z01 Low Battery’ will
be displayed; whereas if ‘Z02 Low Battery’ is
displayed, it implies Magnetic Contact is in low
battery status.
TEST MODE
Code:
RF Environment
Test RF
Environment
Send SMS Test Digital Dialer Test Voice Dialer Test
Test Phone No.1
Stop -> ESC
GSM Gateway
Service On/Off
Relay Test
Wirefree Siren
Service On/Off
Service On/Off
Wait for 10s
Walk Test
Waiting
Alarm Test
Wireless Siren
Test Hardwired Siren
Test
