1. Press
, ,
to put the system into Test mode.
‘WALK TEST’ will be displayed.
2. Press to activate Walk Test.
‘ Walk Test Waiting…’ will be displayed.
3. Walk into and move slowly around the protected
area, each time the detector senses movement the
LED behind the lens will flash. In addition, the
Smart Home Box will chime to indicate that the
alarm signal has been received and the identity of
the zone that the detector is configured for will be
displayed.
If necessary adjust the detection range by changing
the mounting position of the PCB within the PIR
housing.
Note: In normal operation, the LED behind the PIR
lens will not flash on movement detection, (unless
the battery is low).
If necessary re-adjust the detection pattern by
changing the mounting position of the PCB within
the PIR housing.
4. Remove the back cover of the PIR detector. The
Smart Home Box should chime and display ‘PIR
Detector Tamper’ to show that the detector’s tamper
switch has been activated.
5. Press to return to the top level menu of
TEST MODE.
6. Reconfigure the PIR Detector for normal mode by
setting DIP1 of SW2 to OFF and refit in position.
Note: When the detector is fully installed i.e. battery
cover is refitted; the unit will not detect movement for
approximately 2 minutes after each activation. (This
feature is present to conserve battery power and
maximize the battery life).
MAGNETIC CONTACT
DETECTOR(S)
The Magnetic contact consists of two parts; a Detector
and a Magnet. They are designed to be fitted to doors
or windows with the Magnet mounted on the opening
part and the Detector mounted on the fixed frame.
Opening the protected door/window will remove the
magnetic field, trigger the Detector and generate an
alarm condition, (if the system is armed and the alarm
zone active).
The Detector is powered by one 3.6V 1/2 AA size
Lithium cells which under normal conditions will have
typical life in excess of 5 years. Under normal battery
conditions with battery cover fitted the LED on the
Detector will not illuminate when the Detector is
triggered, (unless in test mode). However, under low
battery conditions this LED will be illuminated when the
detector is triggered. When this occurs the battery
should be replaced as soon as possible.
For double security, there are two tamper switches
fitted on the Detector. Either removing the Detector
from the protected door/window or removing the
battery cover will generate a full alarm condition.
The Magnetic Contact Detector is of self-contained
wired Magnetic Contact. This contact must be of a
normally closed contact type with the contacts being
opened in order to generate an alarm condition.
CHOOSING A MOUNTING LOCATION
The Magnetic Contact Detector is suitable for mounting
in dry interior locations only.
Decide which doors/windows are to be protected by
Magnetic Contact Detectors, (usually the front and
back doors as a minimum will have Magnetic Contact
Detectors fitted). Additional detectors may also be
fitted where required to other vulnerable doors or
windows, (e.g. garage, patio/conservatory doors etc).
Note: Take care when fixing the Detector to a metal
frame, or mounting within 1m of metalwork (i.e.
radiators, water pipes, etc) as this could affect the radio
range of the device. If required, it may be necessary
to space the magnet and detector away from the metal
surface using a plastic or wooden spacer to achieve
the necessary radio range.
INSTALLING THE MAGNETIC CONTACT
DETECTORS
Ensure that the system is in Test Mode.
1. Undo and remove the fixing screw from the bottom
edge of the Detector. Remove the battery cover by
sliding and lifting it off. (DO NOT use a screwdriver
to lever the cover off).
