PROFIBUS DP MODULE- DATA LINK

DESCRIPTION

Document Data

Date

Date

File name

ProfibusDP_emanual_Burkert_04.doc

19/03/08 19/03/08 19/03/08


9

Slot(1) = "Process Data" 3
EndSlotDefinition

-----------------------------------------

The Configuration correspond to 24 bytes Input and the last byte indicate the Data Type selected .

Changing the last byte in the GSD file it is possible to set the type of the Flow rate:


With the Configuration 0x41,0x0F,0x00 the Flow rate is in % ( 4 byte )

totalizers positive ( 4 byte )

partial

totalizers

positive

(

4

byte

)

totalizers negative ( 4 byte )

partial

totalizers

negative

(

4

byte

)

process flags ( 2 byte )

dynamic variations ( 1 byte )

the Data Type = 0 ( 1 byte )

-----------------------------------------------------------

Number

of

Input

byte

exchanged (

24

byte

)


With the Configuration 0x41,0x0F,0x01 the Flow rate is in technical unit ( 4 byte )

totalizers

positive (

4

byte

)

partial totalizers positive ( 4 byte )

totalizers negative ( 4 byte )

partial

totalizers

negative

(

4

byte

)

process flags ( 2 byte )
dynamic variations ( 1 byte )

the Data Type = 1 ( 1 byte )

-----------------------------------------------------------

Number

of

Input

byte

exchanged (

24

byte

)

The fourth type of configuration consist of 16 byte Input/Output

With this type of configuration is possible to insert or return data from the Flow meter with two indexes

exchanged with the 16 byte Output data.

With the 16 byte Output data it is possible to insert other parameters of the Flow meter in the same way

used with the Acyclic Service and Class 1 and Class 2 Master.


The reference to the Configuration string in the GSD file is:

------------------------------------------------------------------------

Module = "16 Byte Input/Output" 0xC0,0x0F,0x0F

4

EndModule

------------------------------------------------------------------------
The settings in the GSD file for to use this configuration is:

--------------------------------------

SlotDefinition

Slot(1) = "Process Data" 4

EndSlotDefinition
--------------------------------------

The Configuration correspond to 16 bytes Input/Output.

For details about the type of the data see the Section 2 Cyclic Service below in this document.

The fifth type of configuration consist of 24 byte Input/Output


With this type of configuration is possible to insert or return data from the Flow meter with two indexes
