TECHNICAL MANUAL

Rev.

Pagine

8/52

Filling By

Checked By

03

PROFIBUS DP MODULE- DATA LINK

DESCRIPTION

Document Data

Date

Date

File name

ProfibusDP_emanual_Burkert_04.doc

19/03/08 19/03/08 19/03/08


8

the Data Type = 2 ( 1 byte )

-----------------------------------------------------------

Number

of

Input

byte

exchanged (

16

byte

)

Whit the Configuration 0x41,0x0F,0x03 the Flow rate is in tecnical unit ( 4 byte )

totalizers

negative

(

4

byte

)

partial totalizers negative ( 4 byte )
process flags ( 2 byte )

dynamic variations ( 1 byte )

the Data Type = 3 ( 1 byte )

-----------------------------------------------------------

Number

of

Input

byte

exchanged (

16

byte

)

Whit the Configuration 0x41,0x0F,0x04 the Flow rate is in % ( 4 byte )

totalizers

positive (

4

byte

)

totalizers

negative

(

4

byte

)

process flags ( 2 byte )

dynamic variations ( 1 byte )
the Data Type = 3 ( 1 byte )

-----------------------------------------------------------

Number

of

Input

byte

exchanged (

16

byte

)

Whit the Configuration 0x41,0x0F,0x05 the Flow rate is in tecnical unit ( 4 byte )

totalizers

positive (

4

byte

)

totalizers

negative

(

4

byte

)

process flags ( 2 byte )

dynamic variations ( 1 byte )

the Data Type = 3 ( 1 byte )

-----------------------------------------------------------

Number

of

Input

byte

exchanged (

16

byte

)

The third type of Configuration consist of 24 byte Input

This configuration is used when there is necessary to exchange the information about totalizers positive and

negative at the same time.

The difference with the precedent configurations is the presence of the totalizers positive and negative
contemporary in the block of data exchanged

With the setting of a control byte, in the configuration string of the file GSD,it is possible to set the Data

Type of information returned by Input data.

The control byte is the third byte of the Configuration string (see below).

It is also possible to change the Data Type with a Class 1 and Class 2 Master and the relative Acyclic Slot

and Acyclic Index, during data exchange.
For details Acyclic Service see the relative section in this document.

The reference to the Configuration string in the GSD file is:

------------------------------------------------------------

Module = "24 Byte Input" 0x41,0x17,0x00
3

EndModule

------------------------------------------------------------

The settings in the GSD file for to use this configuration is:

-----------------------------------------

SlotDefinition
