0110 --> 93.75 kBd
0111 --> 45.45 kBd
1000 --> 19.2 kBd
1001 --> 9.6 kBd
byte 9: (8 bits integer) DP state machine
bit 0-1 = 11 --> Data_Exchange
INDEX Input = 32(dec) Internal Data
byte 0: (8 bits integer) current INDEX Input
byte 1: (8 bits integer) current INDEX Output
byte 2: (8 bits integer) slave software version (major number)
byte 3: (8 bits integer) slave software version (minor number)
byte 4-9: (8 bits integer) device name («ML 210», «ML M3F»)
byte 10: (8 bits integer) Flow meter software version (major number)
byte 11: (8 bits integer) Flow meter software version (minor number)
byte 12-13: (8 bits integer) (16 bits unsigned integer, byte 13=MSB):hardware / software enabling flags,
bit 0 = LSB, bit 15 = MSB:
Bit
s
Funzioni ML 210/M3F
0-2 current access level (0..7)
3
channel 1 impulses in use
4 channel 2 impulses in use
5 channel 1 frequency in use
6 channel 2 frequency in use
7 scale range 2 in use
8 specific weight in use
9 additional output 3 present
10 additional output 4 present
11 output 4..20 mA 2 present
12 RS232
present
13 batching functions active
14 output 4..20 mA 2 present
15 RS485
present
byte 14: (8 bits integer) current language set in the Flow meter
Format of the returned data:
0(dec) = English
1(dec) = Italian
2(dec) = French
3(dec) = Spanish
NOTE: For reading the type of language it is first necessary to send to the slave the relative command, see
the INDEX Output = 10 (below in this section) and then read the type of language in the byte 4.
INDEX Input = 40(dec) Batch Data
