byte 2: 0x06 Æ Command
-----------------------------------------------------------------------------------------------------------------------------
es.
Reading current type language of the Flow Meter
byte 0: 0x20 = 32(dec) index input Æ see INDEX Input = 32(dec)
byte 1: 0x0A = 10(dec) index output
byte 2: 0x07 Æ Command
-----------------------------------------------------------------------------------------------------------------------------
es.
Writing the type language in the Flow Meter after the firsly reading of the current language set in the meter
byte 0: 0x20 = 32(dec) index input Æ see INDEX Input = 32(dec)
byte 1: 0x0A = 10(dec) index output
byte 2: 0x60 = 96(dec) Command for set language
byte 3: 0x01 Æ set italian language in the meter
-----------------------------------------------------------------------------------------------------------------------------
es.
Set Autozero Calibration
byte 0: 0xXX = index input
byte 1: 0x0A = 10(dec) index output
byte 2: 0x32 Æ Command
-----------------------------------------------------------------------------------------------------------------------------
INDEX Output = 20(dec) Setting Data and Time in the Flow Meter (only for ML 210)
byte 0: (8 bits integer) INDEX Input: the value set the type of the Input data
byte 1: (8 bits integer) INDEX Output = 20(dec)
byte 2-5: 32 bits long integer containing the date and time expressed in minutes starting from 01-01-
1992 the most significant byte must be sent first.
INDEX Output = 40(dec) Batch Commands
For to use the batch function it is firstly necessary to set ON the menu Batch in the Flow Meter ( see the
Flow Meter Manual )
byte 0: (8 bits integer) INDEX Input: the value set the type of the Input data
byte 1: (8 bits integer) INDEX Output = 40(dec)
byte 2: (8 bits integer) batch Command
0x10(hex) Read the batch data memory, the data are returned with the INDEX Input = 40(dec)
byte 3: (8 bits integer) batch Code
