03 PROFIBUS DP MODULE- DATA LINK
DESCRIPTION
Document Data Date Date
File name ProfibusDP_emanual_Burkert_04.doc 19/03/08 19/03/08 19/03/08
48
Acyclic Index Write = 11(dec) Command for Set Language in the Flow Meter
Command for set the type of language in the meter ( Note: It is firstly necessary to read the type of the
language of the meter, for to set it with this command )
Byte 0 = type of language:
0x00 = 0(dec) = English
0x01 = 1(dec) = Italian
0x02 = 2(dec) = French
0x03 = 3(dec) = Spanish
Acyclic Index Write = 20(dec) Setting Data and Time in the Flow Meter
byte 0-4: 32 bits long integer containing the date and time expressed in minutes starting from 01-01-1992
the most significant byte must be sent first.
NOTE: The date and time are expressed with a 32 bit integer containing the number of minutes elapsed
since 01-01-1992. To calculate the date starting from this number, see the programming examples in the
section 4.0 PROGRAMMING ALGORITMS of this manual.
Acyclic Index Write = 21(dec) Enable/Disable Flow rate Control with Diagnostic message and
Alarms
byte 0: (8 bits integer) enable/disable Flow meter control with thresholds and Diagnostic message
Type of command that is possible to insert in the byte 0:
0 = Control of the Flow rate disabled
1 = Control of the Flow rate enabled, if the value of the Flow rate exceed one of the four thresholds the
slave send the relative Diagnostic message
byte 1: (8 bits integer) enable/disable Process Alarm message
Type of command that is possible to insert in the byte 1:
0 = Alarms disabled
1 = Alarms enabled, if the value of the Flow rate exceed one of the four thresholds the slave send Process
Alarm message
Acyclic Index Write = 30(dec) Batch Commands
For to use the batch function it is firstly necessary to set ON the menu Batch in the Flow Meter ( see the
Flow Meter Manual )
byte 0: (8 bits integer) batch Command
0x10(hex) Read the batch data memory, the data are returned with the Acyclic Index Read 30
0x11(hex) Write the batch data memory, the data are firstly inserted with Acyclic Index Write 31
0x12(hex) Set batch with the code in the byte 1
byte 1: (8 bits integer) batch Code
Type of command that is possible to insert in the byte 1:
0x01(hex) = command for reading the current batch status ( see Acyclic Index Read 30 for to read
