PROFIBUS DP MODULE- DATA LINK

DESCRIPTION

Document Data

Date

File name

ProfibusDP_emanual_Burkert_04.doc

19/03/08 19/03/08 19/03/08

/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////

/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////

Below there is a description of the contents of each 24 bytes for every type of INDEX Output ( this index
is inserted with the second byte of the Output data):

NOTE: Setting the commands only in the state OPERATE. In the state CLEAR the commands are not

accepted.

INDEX Output = 10(dec) Flow Meter Commands

byte 0: (8 bits integer) INDEX Input: the value set the type of the Input data

byte 1: (8 bits integer) INDEX Output = 10(dec)

byte 2: (8 bits integer) command type

Type of command that is possible to insert in the byte 2:

Byte 2 = 0x06(hex) command for reset the Totalizers of the Flow Meter ( see the Flow Meter Manual and

the relative menu for to enable which totalizers to reset by this command).

Byte 2 = 0x07(hex) command for read the current Language used in the Flow Meter:

The information is returned by the byte 4 of the Input data with Index Input 32.

Byte 2 = 0x08(hex) command for Reset the slave module. After 5 seconds the module return in the data

exchange.

Byte 2 = 0x32(hex) command for Autozero Calibration

Byte 2 = 0x60(hex) command for set the type of language in the meter ( Note: It is firstly necessary to

read the type of the language of the meter, for to set it with this command )

Byte 3 = type of language:

0x00 = 0(dec) = English
0x01 = 1(dec) = Italian

0x02 = 2(dec) = French

0x03 = 3(dec) = Spanish

es.

Reset Totalizers

byte 0: 0xXX = index input

byte 1: 0x0A = 10(dec) index output
